LD 30~60kw柴油发电机组

产品摘要:

LD Diesel Generator Set is equipped with our own manufactured LD Diesel Engines, Wattek alternator ( produced by Stamford technology), and Smartgen Controller 6120.


产品描述

Engines ApplicationsEquipped our own LD4F, LD4D engines, lower fuel consumption, lower noise, convenient maintanecne,
and share spare parts with Yuchai engines parts supply system;

Alternator & ControllerWattek brand alternator 184, 224, made by Stamford technoloty; Smartgen controller 6120, the best controller brand in China

Genset Characteristics 24V Electric start; radiator can meet environment temperature 50 degree;

Genset Model (LD Brand)

LD30GF

LD40GF

LD50GF

LD60GF

Rated Power/Speed (kw/r/min)

30/1500

40/1500

50/1500

60/1500





LD4F, LD4D Engine

Engine Model

LD4F50

LD4F65Z

LD4D85Z

LD4D110L

Rated Power/Speed kw/r/min

33/1500

42/1500

55/1500

73/1500

Type

Vertical,inline, water-cooled, four stroke

Intake Way

Natural

Turbocharged

Turbo & Inter-cooled

No- cylinders×bore×stroke (mm)

4-100×117

4-108x120

Total displacement(L)

3.7

4.4

Min fuel consumption (g/kw.h)

≤205

Starting type

Electric

Speed governor model

Mechanical

Oil capacity(L)

10-12

11-13

Low noise limit dB (A)

98





Wattek Alternator



Alternator model

184H

224D

224E

224F

Rated voltage (V)

400/230 or 380/220

Current( A)

54

72

90

108

Freq( Hz)

50

Regulator approach

AVR

Power factor (CosØ)

0.8 Lagging

Phase

3Phase 4Wire

Insulation Class

F / H

Protection Class

IP22 / IP23

Genset Packing

Net weight (kg)

720

800

Genset dimension L*W*H (mm)

1700×700×1300

1700x700x1300
