LD 80~180kw柴油å‘电机组
产品名称:
LD 80~180kw柴油å‘电机组型号:
LD Diesel Generator价格:
FOB Shenzhen $5100~9000最小起订量:
1
产品摘要:
LD Diesel Generator Set is equipped with our own manufactured LD Diesel Engines, Wattek alternator ( produced by Stamford technology), and Smartgen Controller 6120.
- 产品描述
Engines ApplicationsEquipped our own LD6B, LD6LA engines, lower fuel consumption, lower noise, convenient maintanecne,
and share spare parts with Yuchai engines parts supply system;
Alternator & ControllerWattek brand alternator 274, made by Stamford technoloty; Smartgen controller 6120, the best controller brand in China
Genset Characteristics 24V Electric start; radiator can meet environment temperature 50 degree;Genset Model (LD Brand)
LD80GF
LD100GF
LD120GF
LD150GF
LD160GF
LD180GF
Rated Power/Speed (kw/r/min)
80/1500
100/1500
120/1500
150/1500
160/1500
180/1500
LD6B, LD6LA Engine
Engine Model
LD6B135Z
LD6B170L
LD6B210L
LD6LA245L
LD6LA265L
LD6LA285L
Rated Power/Speed kw/r/min
90/1500
114/1500
139/1500
165/1500
176/1500
192/1500
Type
Vertical,inline, water-cooled, four stroke
Intake Way
Turb
Turbocharged & Inter-cooled
No-cylinder×bore×stroke(mm)
6-108×125
6-108×140
Total displacement(L)
6.9
7.7
Min fuel consumption(g/kw.h)
≤205
≤195
≤200
≤195
Starting type
Electric
Speed governor model
Mechanical
Electric
Oil capacity(L)
14-17
18-20
Low noise limit dB (A)
≤102
Wattek Alternator
Alternator model
274C
274D
274E
274G
274H
274J
Rated voltage (V)
400/230 or 380/220
Current( A)
144
180
216
270
288
324
Freq( Hz)
50
Regulator approach
AVR
Power factor (CosØ)
0.8 Lagging
Phase
3Phase 4Wire
Insulation Class
F / H
Protection Class
IP22 / IP23
Genset Packing
Net weight (kg)
1300
1700
Dimension L*W*H (mm)
2400×800×1400
2600×800×1400
